The electric pallet truck is an efficient, environmentally friendly, and reliable handling equipment, which plays an important role in improving efficiency, reducing costs, and protecting the environment in the logistics industry. Electric pallet truck is commonly used in warehouses, factories, and distribution centers for moving and transporting heavy loads over short distances.
Semi-electric pallet trucks use an electric motor for lifting, while Full-electric pallet trucks utilizes an electric motor for both driving and lifting functions. The motor powers the wheels, enabling the operator to move the pallet jack forward, backward, and steer it. It also operates the hydraulic system, which raises and lowers the forks to lift and lower loads.
Our pallet trucks are designed for easy maneuverability in tight spaces. They feature a compact and ergonomic design, allowing operators to navigate narrow aisles and congested areas with ease. The controls are typically located on the handle, enabling precise and efficient operation.
Electric pallet jacks with lead acid batteries are user-friendly and straightforward to operate. Fingertip controls on truck hands are easy to operate, safety to control.
Product Code |
SY-SES20-3-550 |
SY-SES20-3-685 |
SY-ES20-2-685 |
SY-ES20-2-550 |
Battery Type |
Lead Acid Battery |
Lead Acid Battery |
Lead Acid Battery |
Lead Acid Battery |
Battery Capacity |
48V20Ah |
48V20Ah |
48V20Ah |
48V20Ah |
Travel Speed |
5km/h |
5km/h |
5km/h |
5km/h |
Battery Ampere hours |
6h |
6h |
6h |
6h |
Brushless Permanent Magnet Motor |
800W |
800W |
800W |
800W |
Load Capacity(kg) |
3000kg |
3000kg |
2000kg |
2000kg |
Frame Sizes (mm) |
550*1200 |
685*1200 |
550*1200 |
685*1200 |
Fork Length(mm) |
1200mm |
1200mm |
1200mm |
1200mm |
Min Fork Height(mm) |
70mm |
70mm |
70mm |
70mm |
Max Fork Height(mm) |
200mm |
200mm |
200mm |
200mm |
Dead Weight(kg) |
150kg |
155Kg |
175kg |
170Kg |
☑ Emergency Stop Switch Button Equipped With Pallet Truck: Red color and simple structure, easy to identify; emergency cut-off, reliable and safety.
☑ Casters are Universal Wheel of Pallet Truck : optional universal wheel, excellent stable chassis configuration,help to increase stability.
☑ Pallet Truck Body Adopt Alloy-Iron: Formed heavy gauge steel provides maximum fork strength and longevity, durable and reliable. Ditch the plastic and adopt a crash-resistant, sturdy all-iron body.
